Performing the Power-On Self Test (POST) ------ UART Channel Loopback Test Examples Of Texas Drivers License. ...PASS Testing the System SDRAM....PASS Boot1 Checksum Test....PASS Boot2 Checksum Test....PASS Flash Image Validation Test...PASS BOOT Software Version 1.0.0.03 Built 08-Jun-2004 09:48:10 CPU - FireFox 88E6218 ARM946E-S processor 64 MByte SDRAM. I-Cache 8 KB. D-Cache 8 KB. Cache Enabled. Autoboot in 2 seconds - press RETURN or Esc. To abort and enter prom.

Downloading using Xmodem Download After the software has been downloaded. Firecore Promo Code Using your code. SRW2024, SRW2048, SRW224G4.

Preparing to decompress. Decompressing SW from flash HOSTG_rscode_file_load: could not load file Perform WARM BOOT. When I go to the Hyperterminal an press 'Downloading from Xmodem' and select Send File. Select the firmware image (older FW) and choose Xmodem as the protocol, then I get an error:-( Is here anybody reactivated the switch from this loop with an older fw? Thankyou K.R. Just wanted to give an update for the users still using or have a SRW2016 or SRW2024 switch stuck in a loop. Since you cannot access the switch via telnet or http you must connect through the serial/console port and load an older rev of the firmware to get the switch out of the loop.

It appears the older versions of boot code do not like the 1.2+ firmware. The easiest way to get back normal operation of the switch is, as stated above. Load an older rev of the firmware through the serial port with Xmodem. Once you have an operating switch, you can then load the newest rev of boot code, reboot, then load (through serial again) the latest 1.2+ firmware.

There are already posts on here going through the step-by-step details of this process, but if you find yourself lost, email/msg me and I will help. Thanks -Adam.

I had my SRW2024 stuck in a loop after upgrading to version 1.2.2. I was successfully able to downgrade back to 1.00.86 using the XMODEM method and breaking the loop after the POST. I did not have access to a LinkSys cable. I first tried a serial cable, then a null modem cable and finally had to build a custom cable to connect to the console port. Pinouts are 1-1, 2-2, 3-3, 4-4, 5-5, 6-6, 7-7, 8-8 and 9-9. Each pin is straight through. Everything I have read indicates that I need to upgrade my boot code as well as the firmware.
